Changing the Paper Exit Location
(Pedestal Models Only)
On pedestal model printers you can select
whether the paper exits from the rear or from
the top of the printer. Normally, you should
select the top exit only when you will be
tearing the forms from the printer and using
them soon after printing. Forms will not stack
when in this mode.
Setting Top Paper Exit
Press Stop to place the printer in
NOT READY state.
If there is paper in the printer , unload the
paper (page 41), then continue with step 2
of this procedure.
2
Open the printer cover.
3
Loosen the two hinge adjustment
thumbscrews.
4
Slide the cover toward the rear of the
printer until it stops.
22
note
Thumbscrew
Operator' s Guide
