reloading paper
3
On cabinet models:
Ensure the paper is aligned
with the label in the output area
(inside the cabinet). Close the
cabinet front door.
32
Align the top of the first print
line with the top–of–form
indicator on the tractor by
rotating the vertical position
knob.
33
Lower the forms thickness
lever. Set it to match the paper
thickness. Refer to the note on
the shuttle cover.
34
Press Stop to clear any fault
messages (such as "END OF
FORMS") from the message
display.
35
Press Set Top Of Form. The paper
moves to the top-of-form set
previously.
If there is data in the printer buffer,
the paper moves forward to the last
print position on the next page.
36
Press Start and close the printer
cover.
40
A
Thin Paper
B
Medium Paper
C
Thick Paper
NOTE:
Thin Paper = single sheet
Medium Paper = two–part form
Thick Paper = six–part form
