72 C 2: I
HAPTER NSTALLING THE
Client Machine Client Machine
W
EBCACHE
You must have an IP stack correctly installed on the client machine.
I
You can check this by trying to browse the World Wide Web; if you
can browse, an IP stack is installed. If you do not have access to the
World Wide Web, you can check that the IP stack is installed by
pinging another device in your network. For further information, see
"Pinging Other Devices"
Setting Up Using a Cross-over Cable
Alternatively, you can directly connect a client machine to the Webcache
by attaching a cross-over cable to the LAN port on the rear panel. For
further information, see
Figure 25 Setting Up Using a Cross-over Cable
Connected Using a Cross-over Cable
Accessing the Web Interface
To access the Web interface:
1 Open the Web browser on the management workstation. To display the
Web interface correctly, use one of the following Web browsers:
Microsoft Internet Explorer v4.0
I
Microsoft Internet Explorer v5.0
I
Microsoft Internet Explorer v5.5
I
Microsoft Internet Explorer v6.0
I
Netscape Communicator v4.5
I
Netscape Communicator v4.6
I
Netscape Communicator v4.7
I
Netscape Communicator v6.0
I
3Com recommends that you use a later version of Internet Explorer than
version 5.0.
For the browser to operate the Web interface correctly JavaScript
Cascading Style Sheets must be enabled on your browser. These features
are enabled on a browser by default. You will only need to enable them if
you have changed your browser settings.
on page 228.
"Webcache — Rear View Detail" on page 62.
1
2 2 3 3 LAN LAN LAN WAN
Cache Storage Status Activity Activity Power/Self test
Link Status
Cache Storage Status green = ok Webcache 3000
yellow = failed Link Status green = 100 Mbps
yellow = 10 Mbps
3C16116
SuperStack 3
®
Webcache
™
and
