112 C 6: C
HAPTER ONFIGURING
Configuring
Transparent Cache
Mode
Configuring WCCP
V1
D M
EPLOYMENT ODES
To configure Transparent Cache mode using the Web interface:
1 Log in to the Web interface.
2 Click Caching on the Toolbar.
3 Select Set Caching Mode. The Set the Webcache Deployment Mode
screen is displayed.
4 Ensure that Enable Transparent Mode is checked.
5 In the Transparent/Inline Mode Ports field, enter a comma-separated list
of all the ports that the Webcache will listen on.
For further information, see
page 36.
To configure WCCP V1 using the Web interface of the Webcache:
1 Log in to the Web interface.
2 Click Caching on the Toolbar.
3 Select Set Caching Mode. The Set the Webcache Deployment Mode
screen is displayed.
4 Ensure that Enable Transparent Mode is checked and click OK to save this
information.
5 Select WCCP Setup in the Navigation Tree. The WCCP Setup wizard is
displayed.
6 Check Enable WCCP.
7 Select WCCP V1.0.
8 Enter the IP address of the Cisco router that will redirect traffic to the
Webcache in the Router IP Address field and click Next.
9 The Finish screen is displayed. Carefully read the summary information,
which displays the WCCP version and Router IP Address that you have
selected. Click Finish.
You should repeat this configuration process for each additional
Webcache that you want the Cisco router to operate with.
"Transparent Cache Deployment" on
