Throttle EXP/TH-EXP (Throttle system)
This function makes throttle stick high side and brake side direction servo operation
quicker or milder. It has no effect on the servo maximum operation amount.
For the high side, selection from among three kinds of curves (EXP/VTR/CRV) is
also possible.
Advice
When the course conditions are good and there is no sense of torque at the power unit,
set each curve to the + side (quick side). When the road surface is slippery and the
drive wheels do not grip it, set each curve to the - minus (mild) side.
Calling the setup screen
* Calling from menu screen
(Initial screen)
Use the
button to select the
menu screen.
MENU
Press the
MENU SELECT
Use the
button to select the
function.
Press the
* When the direct call button is set,
the setup screen is also called by the
following method:
(Initial screen)
Press the
button simulataneously.
DIRECT SEL
Press the button set
at this function.
Adjustment method for EXP curve
(Preparation)
- Select "EXP" at setup item "F-TYP".
- Select setup item "RATE" and make the following ad-
justments:
1 Forward side adjustment
Use the (+) button to adjust the + side when you
want to quicken the rise and use the (-) button to
adjust the - side when you want to make the rise
milder.
2 Brake side adjustment
Select "BRAKE" by pressing the (DN) button
twice, and use the (+) button to adjust the + side
40
Use the
select the setup item.
*
setup item.
or
button.
or
button.
and
Throttle EXP/TH-EXP (Throttle system)
Curve selection
or button to
First, select the type of forward side
curve at the "F-TYP" item. The setup
blinks at the current
item (screen) varies with the type of
curve. The figure at the bottom left is
the EXP curve setup screen.
Setup items
RATE
F-TYP
BRAKE : Brake side rate
Adjustment range
RATE
F-TYP : EXP, VTR, CRV
BRAKE : -100 ~ 0 ~ +100%
Adjustment buttons
- Use the (+) or (-) buttons to make ad-
justments.
- Return to the initial value by pressing
the (+) and (-) buttons simultaneously
(approx. 1 sec).
Setup item switching
0 Use the (DN) or (UP) button to
switch the setup item.
: Forward side rate
: Forward side curve selection
: -100 ~ 0 ~ +100%
(Mild)
