FUTABA 3VCS Instruction Manual page 21

RF Module
Removal
1. Pull the RF module forward while
pressing the tabs at the top and
bottom inward.
Insertion
1. Insert the RF module while being
careful not to bend the transmitter
side connector pins.
2. Insert the RF module until the tabs
at the top and bottom snap in place
with a "click".
RF Module Temperature Rise
The temperature of the RF module will rise slightly during operation.
Data Backup
The data (transmitter and Data Pac) of each function of the 3VCS transmitter is
stored in a memory element that does not require backup battery. Therefore, the
transmitter can be used without paying attention to the life of the backup battery. The
set data is not lost even when the transmitter battery is changed.
Handling the CAMPac-16K / Data Pac DP-16K
The data for ten models can be stored in the transmitter memory and the data for
ten more models can be stored in the removable CAMPac-16K (optional).
Do not use any removable memories other than CAMPac-16K
CAMPac-16K
(Optional)
Removal Precautions
Always turn off the transmitter power before
installing and removing the CAMPac-16K.
22
RF module
TZ-FM
Tabs
RF.MODULE
FOR
TRANSMITTER
PHONE
CAMPac slot
