Adjuster - FUTABA 3VCS Instruction Manual

Steering stick and throttle stick correction can be applied. Use this function when a
mechanical offset has occurred for some reason.
However, when correction was executed, it may be necessary to recheck
the set values of all the setup functions.
Calling the setup screen
* Calling from menu screen
(Initial screen)
Use the
button to select the
menu screen.
MENU
Press the
MENU SELECT
Use the
button to select the
function.
Press the
* When the direct call button is set,
the setup screen is also called by the
following method:
(Initial screen)
Press the
button simulataneously.
DIRECT SEL
Press the button set
at this function.
Steering adjustment
(Preparation)
- In the steering side selected state, select the adjustment screen
by pressing the (SEL) button.
1 (Steering neutral adjustment)
In the neutral setup screen (figure at the right) state,
lightly pull the steering stick and then press the (SEL)
button in the state in which the stick is not being touched.
2 (Steering throw adjustment)
In the throw setup screen (figure at the right) state, lightly
turn the stick fully to the left and right and press the (SEL)
button.
3 (Correction execution)
At the check screen (figure at the right), check if neutral
is near "0%) and that the left and right throws are near
"130%" and press the (+) and (-) buttons simultaneously.
Internal checks are performed automatically and when
each adjustment point is in a fixed range, correction is
performed and "SUCCESSFUL!" (figure at the right) is
displayed.
If an adjustment point is not within a fixed range, an error
90
Adjuster/ADJUSTER
Use the
select the setup item.
*
setup item.
or
button.
or
button.
and
Adjuster/ADJUSTER
or button to
blinks at the current
Steering
Throttle
