The graphic liquid crystal screen display mode, buzzer sound, pilot lamp display
mode and initial screen display mode can be set.
The system function setup items cannot be set for each model.
- Liquid crystal screen backlighting display mode setup (OFF, ON at button opera-
tion, normally ON)
- Setting of ON time (1~30 secs) when [ON at button operation] was selected above.
- Liquid crystal screen contrast adjustment (20 steps)
- Buzzer sound tone adjustment (OFF, 100 steps)
- Pilot lamp display color setup (OFF, 7 colors)
- Initial screen display mode setting ("Futaba" display, timer display, servo display,
Users name)
Calling the setup screen
* Calling from menu screen
(Initial screen)
Use the
button to select the
menu screen.
MENU
Press the
MENU SELECT
Use the
button to select the
function.
Press the
* When the direct call button is set,
the setup screen is also called by the
following method:
(Initial screen)
Press the
button simulataneously.
DIRECT SEL
Press the button set
at this function.
92
System function/SYSTEM
Use the
select the setup item.
*
setup item.
or
button.
or
button.
and
System function/SYSTEM
Setup items
LHT-MODE
LHT-TIME
CONTRAST
or button to
BUZ-TONE
blinks at the current LED-MODE
DISP-SEL
*When "KEY-ON" was selected at
backlighting mode, "ACT" is displayed
and the backlighting time setting be-
comes effective.
Adjustment buttons
- Use the (+) and (-) buttons to make
adjustments.
- Press the (+) and (-) buttons simulta-
neously (approx. 1 sec) to return to
the initial screen.
: Backlighting mode
: Backlighting time
: Contrast
: Buzzer tone
: LED color
: Initial screen mode
