FUTABA 3VCS Instruction Manual page 80

Calling the setup screen
* Calling from menu screen
(Initial screen)
Use the or
button to select the
menu screen.
MENU
Press the button.
MENU SELECT
Use the or
button to select the
function.
Press the button.
* When the direct call button is set,
the setup screen is also called by the
following method:
(Initial screen)
Press the and
button simulataneously.
DIRECT SEL
Press the button set
at this function.
Function selection
Function select dial setup
1 (Setup item selection)
Use the (DN) or (UP) button to select the item to
be set.
2 (When changing function)
Use the (DN) or (UP) button to select the func-
tion.
- See the preceding page for the function abbreviations.
(When setting the step amount)
Use the (+) or (-) button to set the step amount.
- See the preceding page for the relationship between set value and step
amount.
(When changing the direction of operation)
Use the (+) or (-) button to switch the direction.
3 When ending setup, return to the initial screen by
pressing the (END) button 3 times.
Use the or button to
select the setup item.
* blinks at the current
setup item.
Step amount setting
Function select dial/FUNC-DIAL
* Setup item shifts in function -> step
amount -> direction of operation order
Adjustment buttons
- Use the (+) and (-) buttons to make
adjustments.
- Press the (+) and (-) buttons simul-
taneously (approx. 1 sec) to return to
the initial screen.
Direction of operation setting
81
