Throttle speed/TH-SPEED (Throttle system)
Sudden trottle stick operation on a slippery road
only causes the wheels to spin and the vehicle can-
not accelerate smoothly. Setting the throttle speed
function reduces wasteful battery consumption
while at the same time permitting smooth, enjoy-
able operation.
Operation
Throttle servo (amp) operation is delayed so that the drive wheels will not spin even
if the trottle stick is operated more than necessary. This delay function is not per-
formed when the trottle stick is returned and at brake operation.
- Low side throttle speed (See [Operation range setup].)
Use when adjusting the speed from the neutral position to the set point.
- High side throttle speed (See [Operation range setup].)
Use when adjusting the high side speed from the set point.
Remark: Regarding the throttle speed set value; the actual delay value varies
depending on the system (HRS, PCM, PPM). The delay when the HRS system is used is approximately 1/
3 that of the PCM and PPM systems.
Operation display
The LED blinks while the throttle speed function is on.
Calling the setup screen
* Calling from menu screen
(Initial screen)
Use the
button to select the
menu screen.
MENU
Press the
MENU SELECT
Use the
button to select the
function.
Press the
* When the direct call button is set,
the setup screen is also called by the
following method:
(Initial screen)
Press the
button simulataneously.
DIRECT SEL
Press the button set
at this function.
44
Use the
select the setup item.
*
setup item.
or
button.
or
button.
and
Throttle speed/TH-SPEED (Throttle system)
TH-SPEED/Smooth, quick starts possible
No TH-SPEED/Tires slip and vehicle does not move
Setup items
RA NGE : Operation range
or button to
SPEED : Speed amount
MODE
blinks at the current
* The LED blinks while the throttle
speed function is on.
* "L40" indicates operation below 40%.
* The black part of the bar graph is
the operation range.
* Throttle trigger position
Adjustment buttons
- Use the (+) and (-) buttons to make
adjustments.
- Return to the initial value by pressing
the (+) and (-) buttons simultaneously
(approx. 1 sec).
: Function ON/OFF
