Dual rate/ST-D/R (Steering system)
Dual rate
When the steering angle is too small at under steering at corners while running, adjust
at the "+" side and when the steering angle is too large at over steering , adjust at the
"-" side. The setup here is linked with transmitter grip dial BT1. Adjustments can be
made at this screen even if BT2 is assigned to another function.
Second dual rate
Use when facing a fence and escape is difficult at a crash and similar cases.
Switch setup
When using second dual rate, the function select switch function must be used to
preselect the switching switch. (See page 82)
Operation
- The steering servo left and right steering angles are adjusted simultaneously.
- Dual rate and second dual rate steering angle switching is performed by switch.
Calling the setup screen
* Calling from menu screen
(Initial screen)
Use the
button to select the
menu screen.
MENU
Press the
MENU SELECT
Use the
button to select the
function.
Press the
* When the direct call button is set,
the setup screen is also called by the
following method:
(Initial screen)
Press the
button simulataneously.
DIRECT SEL
Press the button set
at this function.
84
Use the
select the setup item.
*
setup item.
or
button.
or
button.
and
Dual rate/ST-D/R (Steering system)
or button to
blinks at the current
Setup Item
RATE
2ND D/R
*ON/OFF display. Linked with 2nd
dual rate switch.
Adjustment buttons
- Use the (+) and (-) buttons to make
adjustments.
- Press the (+) and (-) buttons simul-
taneously (approx. 1 sec) to return to
the initial screen.
: Rate setting (D/R)
RATE : Rate setting (2nd D/R)
