Trancemitter T3Vcs - FUTABA 3VCS Instruction Manual

Nomenclature
Pilot lamp
CH3 knob (KNOB)
Switch(SW2)
(See page 19 for
the adjustment
instructions.)
Mechanical
ATL
adjusting
screw
(See page 18 for
the adjustment
instructions.)
Neutral
adjusting
Throttle stick
Throttle trim (DT2)
(See page 17 for the operating
instructions.)
*The switches, knobs, and trimmers in the figure are shown in the initial setting position.
Precautions when turning the power switch on and off.
When the data was changed using the edit keys or trim levers, wait at least two sec-
onds before turning off the power. If the power is turned off within two seconds after
the data was changed, the new data will not be written to memory.
Stick lever head the precautions
There is a small projection at the tip of the lever heads to prevent slipping. When
carrying the transmitter, be careful these projections do not damage your skin,
clothes, or other objects.
Transmitter T3VCS
Antenna
Edit buttons
insertion
(See page 22 for the operating instructions.)
LCD screen
Carryng bar
Display switch
(DSP)
(See page 23 for the operat-
ing instructions.)
Switch(SW1)
Steering stick
Steering trim (DT1)
CAMPac
(See page 17 for the operating
instructions.)
hole
Power
switch
(See page 17 for the op-
erating instructions.)
Digital trim 3
(DT3)
Hook
