ATL Function/TH-ATL(Throttle system)
This function adjusts the "-" side when the braking effect is strong and the "+" side
when the braking effect is weak. This setting is linked to transmitter grip dial BT2.
When BT2 is assigned to another function, set the ATL function with this screen.
Operation
The throttle brake side (when the throttle stick is pushed
forward) brake amount can be adjusted.
Calling the setup screen
* Calling from menu screen
(Initial screen)
Use the
button to select the
menu screen.
MENU
Press the
MENU SELECT
Use the
button to select the
function.
Press the
* When the direct call button is set,
the setup screen is also called by the
following method:
(Initial screen)
Press the
button simulataneously.
DIRECT SEL
Press the button set
at this function.
ATL function adjustment
1 (Brake amount adjustment)
Use the (+) and (-) buttons to adjust the brake
amount.
- Adjust the - side when the braking effect is strong and the + side when
the braking effect is weak.
2 When ending adjustment, return to the initial
screen by pressing the (END) button 3 times.
86
Setup Item
RATE: Brake amount
or
button.
or
button.
and
ATL Function/TH-ATL(Throttle system)
Adjustment buttons
- Use the (+) and (-) buttons to make
adjustments.
- Press the (+) and (-) buttons simulta-
neously (approx. 1 sec) to return to
the initial screen.
Brake amount
0~100%
Initial value: 100%
