Servo Reverse - FUTABA 3VCS Instruction Manual

Servo Reverse/CH-REV(All channel)
This function reverses the direction of operation of the servos related to transmitter
steering, throttle, and channel 3 operation.
However, when the position set by trim or subtrim shifts from the center, the center
becomes the opposite side.
Calling the setup screen
* Calling from menu screen
(Initial screen)
Use the
button to select the
menu screen.
MENU
Press the
MENU SELECT
Use the
button to select the
function.
Press the
* When the direct call button is set,
the setup screen is also called by the
following method:
(Initial screen)
Press the
button simulataneously.
DIRECT SEL
Press the button set
at this function.
Sevo Reverse Function Setting
(Preparation)
- Preselect setup channel "ST", "TH", or "CH3".
1 (Servo reverse setting)
Use the (+) or (-) button to reverse the servo op-
eration direction.
(Each channel can be set similarly.)
2 When ending adjustment, return to the initial
screen by pressing the (END) button 3 times.
72
or
button.
or
button.
and
Servo Reverse/CH-REV(All channel)
* Steering
* Throttle
* Channel 3
* Normal side
* Reverse side
