FUTABA 3VCS Instruction Manual page 23

Display when power switch turned on
Total timer display (H:M)
* Display mode can be changed
by using the SYSTEM function.
(See pge 92)
Model name (10 characters)
Steering trim display
Throttle trim display
User name display
When the (END) button is held down for 1 second or longer at the initial screen, the
Futaba logo and user name are displayed for about 2 seconds.
24
Power switch turned on
Battery voltage display
* Displays whether or not a data
pack is inserted. When a data pack
is inserted, "DPAC" is displayed.
* When radio waves are being emit-
ted, "RF" is displayed. When radio
waves are
not being emitted when turned on by
display switch and when the DSC
function is used, "DISP" is dis-
played.
(END) button
Beep confirmation sound is generated and
the initial screen shown below appears.
DT1
DT2
* Function names and rate
assigned to dials are dis-
DT3
played.
BT1
BT2
KNOB
* "BLHT" is displayed when back-
lighting is ON.
* The current operation mode is dis-
played. ("PPM"/"PCM"/"HRS")
