Audio/Video Windows
Table 3-9
Option
Frame Repeat Count
Options
Enable Time Stamp
Enable Text Display
Day/Night Vision
Switch Mode
Day to Night Threshold If the Switch Mode option is set to Auto, choose the value that specifies the
Night to Day Threshold If the Switch Mode option is set to Auto, choose the value that specifies the

Audio Window

The Audio window provides options for enabling and configuring audio that is transmitted to and from
the IP camera. You can configure audio for these devices:
Cisco Video Surveillance System IP Camera User Guide
3-20
Video Window Options (continued)
Description
Designates how video output from the IP camera displays. The IP camera
generates two independent fields (odd and even) for each video capture,
which occur 60 times per second for NTSC or 50 times per second for PAL.
When Frame Repeat Count is set to 1, the IP camera combines one odd and
one even field to compose a video frame. When Frame Repeat Count is set
to 2, the IP camera uses one of the fields two times to compose a video frame.
A setting of 1 provides smoother video. It is designed for software that can
display interlaced video.
The default value is 2.
Check this check box to display the time from the internal clock of the IP
camera as an overlay on the video image from the IP camera.
Check this check box to display designated text as an overlay on the video
image from the IP camera, and enter alphanumeric text of up to 20
characters.
This option can be useful for identifying this IP camera in an installation
with several IP cameras.
Choose the day/night mode for the IP camera:
Auto—IP camera automatically switches between day and night mode
•
based on lighting thresholds that you specify.
Day—IP camera always remains in day mode. In this mode, the camera
•
displays video images in color.
Night—IP camera always remains in Night mode. In this mode, the
•
camera displays video images in black and white.
relative light threshold at which the IP camera switches from day to night
mode. A lower value designates that the IP camera switches from day to
night mode in brighter conditions. A higher value designated that the IP
camera switches modes in darker conditions. The default value is 24.
relative light threshold at which the IP camera switches from night to day
mode. A lower value designates that the IP camera switches from night to
day mode in darker conditions. A higher value designated that the IP camera
switches modes in lighter conditions. The default value is 6.
Chapter 3 Configuring and Managing the IP Camera
OL-14220-02
