Applications Windows
Table 3-16
Option
Actions
Video Attachment
Note
Overwrite/Replace
oldest video file when
SDRAM is full
Video Format
(MPSG-4)
Pre-Capture Length
Post-Capture Length

SNMP Window

The SNMP window allows you to configure Simple Network Management Protocol (SNMP) settings for
the IP camera. These settings can help you manage complex networks by sending messages to different
devices on the network.
Cisco Video Surveillance System IP Camera User Guide
3-30
Event Window Options (continued)
Description
Choose the desired options to designate actions that the camera takes when
events occur:
E-Mail—Causes an e-mail message to be delivered to the SMTP server.
•
The e-mail alerts users that an event has occurred, and may include a
video file of the event and the URL of an FTP server from which users
can download the video file. (For more information about e-mail
messages, see the
FTP—Causes the video file to upload to the FTP server. (The FTP
•
server must be configured as described in the
section on page
• Alarm Output 1—Applies to output port 1 on the IP camera. Causes the
output port state to be activated as configured. (For more information
about output ports, see the
page
Alarm Output 2—Applies to output port 2 on the IP camera. Causes the
•
output port state to be activated as configured (For more information
about output ports, see the
page
Interval—Choose the amount of time, in minutes, that the camera waits
•
after detecting a condition before it triggers an event. A setting of 0
indicates no delay.
These Video Attachment options appear if you enable the Trigger Event option and select the
E-Mail or FTP option.
Check this check box to overwrite the oldest video file that is stored on the
IP camera with the new video file when the SDRAM on the IP camera does
not have enough room for the new file.
If you do not check this option, the IP camera does not save new video files
when its SDRAM does not have room for the files.
Choose the format (asf, mp4, or 3gp) for the video file of the event. If you
choose mp4, or 3gp, video files do not include audio.
Length, in seconds, of additional video that is included in the video file
immediately before the event.
The default value is 0 (no pre-capture video).
Length, in seconds, of additional video that is included in the video file
immediately after the event.
The default value is 5.
Chapter 3
"Mail & FTP Window" section on page
3-24.)
"Alarm I/O Ports Window" section on
3-31.)
"Alarm I/O Ports Window" section on
3-31.)
Configuring and Managing the IP Camera
3-24.)
"Mail & FTP Window"
OL-14220-02
