Chapter 3 Configuring and Managing the IP Camera
Internal microphone—The IP camera includes an internal microphone that can capture audio at the
•
camera location. This audio is sent to the PC that you use to view video from the IP camera. You
can listen to the audio when viewing video in the Home window.
External microphone—You can connect an optional external microphone (available from
•
third-parties) to the IP camera. This audio is sent to the PC that you use to view video from the IP
camera. You can listen to the audio when viewing video in the Home window. Connecting an
external microphone disables the internal microphone.
External speaker— You can connect an optional external speaker (available from third-parties) to
•
the IP camera. This speaker plays audio that is captured by the microphone of the PC that you use
to view video from the IP camera. The PC can capture and send this audio only when the Home
window is open.
To display the Audio window, access the configuration windows as described in the
Initial Setup of the IP Camera" section on page
If you change any options in the Audio window, you must click Save to save the changes. To discard the
changes, click Cancel before clicking Save. These buttons appear at the bottom of the window. You may
need to scroll down to see them.
Table 3-10
These features are not currently supported if you use the IP camera with Cisco VSM.
Note
Table 3-10
Option
Enable Audio
OL-14220-02
describes the options in the Audio window.
Audio Window Options
Description
Check this check box to enable audio from the IP camera, and choose one of
these options:
Simplex - Listen Only—Enables a simplex connection that allows you
•
to receive audio from the IP camera but not transmit audio to the IP
camera
Simplex - Talk Only—Enables a simplex connection that allows you to
•
transmit audio to the IP camera but not receive audio from the IP camera
Half Duplex - Talk or Listen—Enables a half duplex connection that
•
lets you receive audio from and transmit audio to the IP camera, but not
simultaneously
• Full Duplex - Talk and Listen—Enables a full duplex connection that
lets you simultaneously receive audio from and transmit audio to the IP
camera
Note When you enable transmitting audio to the IP camera (which enables
the internal or external microphone), the internal microphone on the
IP camera or an external microphone that is attached to the IP camera
is muted by default. To unmute the microphone, use the Microphone
On toggle button in the Home window. For detailed information, see
the
2-5, click Audio/Video, then click Audio.
"Home Window Controls" section on page
Cisco Video Surveillance System IP Camera User Guide

Audio/Video Windows

"Performing the
4-3.
