DC Auto Iris Lens Connector Pinouts

DC Auto Iris Lens Connector Pinouts
Figure 1-4
camera.
Figure 1-4
Pin
1
2
3
4

Package Contents

The the Cisco Video Surveillance IP Camera package includes these items:
•
•
•
•
•
•
•
•
•
Cisco Video Surveillance System IP Camera User Guide
1-6
and the table that follows describe the pinouts of the DC auto iris lens connector on the IP
DC Auto Iris Lens Connector Pinouts
Function
Damp –
Damp +
Drive +
Drive –
Camera
Lens opening dust cap
Mounting hole protector
Antennas (wireless model only)
Terminal block for power connection
C mount lens adaptor
0.9 mm Allen wrench for unlocking and locking the focus ring
Regulatory Compliance and Safety Information
Quick Start Guide
Chapter 1 Overview
OL-14220-02
