Cisco CIVS-IPC-2500W - Video Surveillance IP Camera Network User Manual page 48

Applications Windows
Table 3-14
Option
SMTP Mail Server
Authentication
Account Name
Password
POP Server Name
E-Mail Setup
Send To
Show "From" as
Subject
E-mail Body
Attach Video Streaming
URL Address
Primary FTP
Primary FTP
FTP Server
Port
Login name
Password
File Path Name
Enable Passive Mode
Secondary FTP
Secondary FTP
FTP Server
Port
Login name
Cisco Video Surveillance System IP Camera User Guide
3-26
Mail & FTP Window Options (continued)
Description
Enter the IP address of the secondary SMTP server.
If the secondary SMTP server requires authentication to send e-mail, choose
the appropriate authentication type. The authentication type typically is the
same as that for the POP3 server that you use to receive e-mail.
If the secondary SMTP server requires authentication, enter the account
name for the server.
If the secondary SMTP server requires authentication, enter the account
password for the server.
Enter the name of the POP3 mail server that you use to receive e-mail.
Enter at least 1 e-mail address to which e-mail messages are sent when an
event occurs. The second and third addresses are optional.
Enter the e-mail address to be shown in the From field for e-mail messages
that are sent when an event occurs.
Enter the text to be shown in the Subject field for the e-mail messages that
the IP camera sends when events occur. The subject can contain up to 48
characters, including spaces.
Check this check box to include in the message body the URL of an FTP
server from which you can download a video file to your local PC.
Check this check box to cause the IP camera automatically upload event
video files to the primary FTP server when the files are created.
Enter the IP address of the primary FTP server to which event video files are
uploaded.
Enter the port number of the primary FTP server to which event video files
are uploaded.
The default value is 21.
Enter the log in name of the primary FTP Server.
Enter the password of the primary FTP Server.
Enter path where the event video file is stored on the primary FTP server.
Check this check box to enable the passive mode feature of the primary FTP
server.
Check this check box cause the IP camera automatically upload event video
files to a secondary (backup) FTP server if the primary FTP server is
unavailable.
Enter the IP address of the secondary FTP server.
Enter the port number of the secondary FTP server.
Enter the log in name of the secondary FTP Server.
Chapter 3 Configuring and Managing the IP Camera
OL-14220-02
