Digital Control DIGITRAK FALCON F5+ User Manual page 91

DIGITRAK FALCON F5+ USER MANUAL
DCI DigiGuide 11.04.2023
Reference
FALCON F5+ SPECIFICATIONS
Product ID: FF5+
Model number: FAR5
Receiving frequencies: 0.33 to 45.0 kHz
Accuracy (1): ±5% of depth reading
Telemetry channels (2): 4
Telemetry range (3): Up to 3000 ft (900 m)
Target steering range (4): 35 ft (10.6 m)
L/R steering range: Range of transmitter
Power source: Lithium-ion battery pack
Battery life: 8–12 hrs
Functions: Menu-driven
Controls: Trigger and toggle switches
Graphic display: Full-color LCD
Audio output: Beeper
Voltage, current: 14.4 VDC nominal, 390 mA max
Operating temperature: -4 to 140° F (-20 to 60° C)
Dimensions: 11 x 5.5 x 15 in (27.94 x 13.97 x 38.1 cm)
Weight (with battery): 8.4 lb (3.81 kg)
Compatible Transmitters: See the article "List of Compatible Transmitters."
Compatible Displays: Compatible remote displays: Aurora and FCD
91
DIGITAL CONTROL, INC
