BASIC - QUICK SCAN PAIR
STEP 1 OF 7
Before You Start
Basic - Quick Scan Pair scans noise and selects the best frequencies for the
preset Up and Down bands. These presets may not be the best bands for the
jobsite.
Use Advanced - Scan Pick Pair t o view noise on all bands.
To provide pitch information on your locators, enable full scale
sensitive pitch (FSSP), see the article "Enable Full Scale Pitch
Resolution" in the Advanced Topics Chapter.
STEP 2 OF 7
Ensure all transmitters are powered off or more than 100 ft (30.5 m) away
from the locator.
Inspect the jobsite and move locator to active noise area of concern or deep
part of bore - keep locator above and parallel to bore path.
STEP 3 OF 7
From the Main menu, select
Quick Scan Pair.
Confirm the pre-selected bands and the power levels on the top box on the
screen.
