DIGITRAK FALCON F5+ USER MANUAL
DCI DigiGuide 11.04.2023
When used with DCI's LWD Mobile app, geo-tagging the entry and exit
automatically ties the as-built to a physical location.
With a DigiTrak DataLog Management (DDM) subscription, use your mobile
device to upload DataLogs to your cloud account even during drilling to show
progress to back-office personnel.
After importing your DataLog job into our Log-While-Drilling (LWD) 3.0
software, you can edit, annotate, and finalize the precise report you or your
customer requires.
On the DigiTrak Aurora remote display, use our free LWD Live app to view the
drill profile in real-time as each rod is completed.
SCREEN ELEMENTS OVERVIEW
The Locate Mode, Depth, and Predicted Depth screens are the primary
screens you will use for locating.
When the locator is detecting a signal from a transmitter, the Locate Mode
screen provides real-time data about the transmitter's location, temperature,
pitch, roll, and signal strength.
Depth data appears when the trigger is held at the Locate Line (LL) and
predicted depth appears when held at the Front Locate Point.
LOCATE MODE SCREEN
