2. Max Mode icon
3. Max Mode timer
4. Transmitter battery strength
STEP 4 OF 4
Take two more Max Mode readings. All three readings must be consistent.
If the readings are not consistent, change the band and try
again. If the readings continue to be inconsistent, turn the
locator off and then on again. If the issue continues, contact DCI
Customer Support.
TARGET STEERING INTRODUCTION
The Target Steering guidance method allows the Falcon locator to be placed
ahead of the drill head and used as a steering target.
Use it to distance the locator from rebar that is causing signal interference
and to drill where walkover locating is not possible.
Target Steering is typically only used on a straight drill path under level
ground, not a curved path, with terrain changes, or to correct a significantly
off-course bore.
The maximum distance the locator can be placed ahead of the drill head for
accurate up/down Target Steering is 35 ft (10.7 m).
Within this range, starting with the drill head approximately level, the
maximum depth and pitch changes are approximately 4 ft (1.2 m) and 14%,
respectively.
Beyond this distance, depth information becomes less accurate.
