Interference varies with time and location, and no band works perfectly in all conditions.
Different bands are better for different kinds of interference. Lower frequency bands
tend to perform better in passive interference. Middle bands can perform better in
deeper bores and may have longer Target Steering capability. Higher frequency bands
have slightly less signal strength but tend to offer better performance around active
interference such as power lines.
CHANGE TRANSMITTER BANDS, TILT METHOD
STEP 1 OF 3
To change the transmitte r band, hold the Tx at the same (±2) general clock
position for this whole procedure.
Hold transmitter powered on at level (0±10°) for at least five seconds.
STEP 2 OF 3
Tilt transmitter up at
approximately +65° (almost
vertical) for 10-18 seconds.
STEP 3 OF 3
Return to level for 10-18 seconds.
If the locator is on the same band as the transmitter, data will appear on the
locator screens.
To change the band on the locator, from Locate Mode screen,
hold the toggle right to open the Band Selection menu. Select
the band without the checkmark. After a few seconds, data will
begin to appear.
