STEP 2 OF 8
Place the locator on the ground.
STEP 3 OF 8
To take a measurement on a slope, tilt the locator left or right so that the
display screen is level.
STEP 4 OF 8
From the Main menu, toggle
down to the second page
and select Diagnostics.
STEP 5 OF 8
Select Surface Grade.
STEP 6 OF 8
The pitch is displayed in degrees.
STEP 7 OF 8
To exit, click Cancel.
