The DCI Warranty does not cover any transmitter that has been
overheated or had the temp dot removed.
TRANSMITTER TEMPERATURE WARNINGS
STEP 1 OF 6
DigiTrak transmitters (Tx), with the exception of DucTrak, have an internal
digital thermometer. The normal below ground temp range is 63° to 104° F.
The Tx temperature displays on the bottom right of the locator screen and
remote display screens.
1. Temperature status icon
2. Temp trend up/down arrows
3. Temperature
Suspend drilling when temperatures increase rapidly.
Temperatures above 111° F are not typical.
STEP 2 OF 6
As the transmitter (Tx) temperature increases above 61° F, the locator and
remote emits warning beeps and the temperature icon changes on the
locator or remote display.
