1. Disable HAG
2. Enable standard HAG
3. Enable TrakStand HAG
4. Set HAG
The locator must be held at this height for accurate depth
readings. TrakStand height can be used with Target Steering.
STEP 4 OF 4
a. To enable TrakStand HAG,
toggle to Enable TrakStand.
Confirm the height. The
height is preset to 0.46m.
The height of a
TrakStand with legs fully
extended is 1' 6"
(0.46m).
The height of a
Trakstand with legs fully
collapsed is 1'9" (0.60m).
b. Select Enable TrakStand.
It is not recommended to change the TrakStand Height. If
needed, Enable Trakstand, return to the Enable HAG screen, and
then select Set HAG to enter a new height. The custom height
will revert back to the pre-set (1'6"/0.46m) after a power cycle.
