CALIBRATE - DOWN
STEP 1 OF 7
From the Main menu, select
Calibration.
STEP 2 OF 7
Select 1 pt calibration.
STEP 3 OF 7
Put the transmitter back in the drill head, put the cover back on, and ensure
the near edge of the locator is still parallel to and exactly 10 ft (3 m) from the
center of the transmitter .
For accurate calibration, always use the center of the
transmitter, not the drill head.
STEP 4 OF 7
Select Continue to calibrate
the Down band.
