To calibrate any other time,
from the Main menu select
Calibration, then 1 pt
calibration before
continuing with the following
steps.
Watch video on YouTube:
Calibrate Your DCI Transmitter and Locator (1:28 min)
https://youtu.be/j2c6FvpAa6k
CALIBRATE - UP
STEP 1 OF 6
Install the powered-on transmitter in the drill head. Place the cover on, but
don't fasten it yet.
STEP 2 OF 6
Using a tape measure, place the near edge of the locator parallel to and
exactly 10 ft (3 m) from the center of the transmitter.
For accurate calibration, always use the center of the
transmitter, not the drill head.
