Chapter 1
CPU
•
Embeddeed VIA Processor
•
Enhanced Ball Grid Array Package (EBGA)
•
Internal L1 128KB and L2 64KB cache memory
Chipset
•
VIA 8601A North Bridge
•
VT8231 South Bridge
Graphics
•
Integrated Trident Blade 3D graphics core
Audio
•
VT1612A 2 channel AC'97Codec
•
3 Audio jacks: Line-in, Line-out and Mic-in
Main Memory
•
2 x PC100/133 DIMM slots.
PCI Bus IDE
•
Ultra DMA 33/66/100
LAN
•
VIA VT6103 10/100 Base-T Ethernet PHY
USB
•
2 USB ports
•
1 onboard USB pin header for up to 2 additional connections
•
USB v1.1 and Intel Universal HCI v1.1 compatible
TV-Out (Optional)
•
VIA VT1621 TV-Out Controller
Specifications
1-2
