Summary of Contents for VIA Technologies VB8001
- Page 1 Operating Guide VB8001 Mini-ITX Mainboard October 16, 2008 Version 1.0...
-
Page 2: Table Of Contents
D. Idle State ........................9 E. Running C.C. Winstone 2004 ..................10 F. S3 Mode ........................10 Power Specifications ......................11 VIA VB8001 Microsoft and Linux Driver Support ..............12 Microsoft Driver Support....................12 Linux Driver Support......................12 Contact ..........................13... -
Page 3: Via Vb8001 Overview
VIA StepAhead™ Technology Suite, and VIA TwinTurbo™ technology. The VIA VB8001 includes sizeable support of up to 4 GB of 667 MHz DDR2 memory and native support for SATA (3 Gbps) storage devices. The VIA VB8001 provides support for high fidelity audio with its included VIA VT1708A High Definition Audio codec. -
Page 4: Via Vb8001 Layout
VB8001 Operating Guide VIA VB8001 Layout October 16, 2008 - 2 - Version 1.0... -
Page 5: Via Vb8001 Specifications
VB8001 Operating Guide VIA VB8001 Specifications Model Name VB8001 Processor VIA Nano 1.6 GHz NanoBGA2 processor with FSB 800 MHz Chipset - VIA CN896 North Bridge - VIA VT8237S South Bridge System Memory - 2 x DDR2 667 / 533 DIMM slot - Up to 4 GB memory size - VIA Chrome9™... -
Page 6: Via Vb8001 Processor Skus
VB8001 Operating Guide VIA VB8001 Processor SKUs The VIA VB8001 is available in two speed grades as follows: • VIA Nano 1.6 GHz NanoBGA2 Processor October 16, 2008 - 4 - Version 1.0... -
Page 7: Via Cn896 Chipset Overview
VB8001 Operating Guide VIA CN896 Chipset Overview The VIA CN896 Chipset is designed to enable high quality digital video streaming and DVD playback in a new generation of fanless, small form factor PCs and IA devices. The VIA CN896 North Bridge features the VIA Chrome9™ HC IGP with 2D/3D graphics and video acceleration, DDR2 667/533/400 MHz support, motion compensation and dual display support to ensure a rich overall entertainment experience. -
Page 8: Via Vb8001 I/O Back Panel
VB8001 Operating Guide VIA VB8001 I/O Back Panel The VIA VB8001 mainboard comes in the ultra compact 17 cm x 17 cm Mini-ITX form factor. Its integrated design supports most of the standard legacy x86 connectivity options including PS/2 mouse port, PS/2 keyboard port, COM port, VGA port, RJ45 LAN ports, USB 2.0 ports, and audio jacks. -
Page 9: Via Vb8001 Dimensions
VB8001 Operating Guide VIA VB8001 Dimensions October 16, 2008 - 7 - Version 1.0... -
Page 10: Via Vb8001 Height Distribution
VB8001 Operating Guide VIA VB8001 Height Distribution October 16, 2008 - 8 - Version 1.0... -
Page 11: Power Consumption
VB8001 Operating Guide Power Consumption Power consumption tests were performed on the VIA VB8001. The following tables are a comprehensive breakdown of the voltage, amp and wattage values while running common system applications. VIA VB8001 A. Playing DVDs with PowerDVD 5.0... -
Page 12: Running C.c. Winstone 2004
VB8001 Operating Guide E. Running C.C. Winstone 2004 Measured Voltage Measure Amp Watts Main Board +3.3V 3.346 1.127 3.771 Main Board +5V 5.019 4.001 20.081 Main Board 5VSB 5.010 0.046 0.230 Main Board +12V 12.143 0.203 2.465 Total Power Consumption 26.547... -
Page 13: Power Specifications
VB8001 Operating Guide Power Specifications The VIA VB8001 mainboard utilizes an industry standard 20-pin ATX power connector for connecting to the power supply. Due to its ultra low power requirements, a 90 – 120 Watt ATX power supply is ample for even the heaviest of multimedia system applications. -
Page 14: Via Vb8001 Microsoft And Linux Driver Support
ICROSOFT RIVER UPPORT The VIA VB8001 mainboard is compatible with Microsoft operating systems. The latest Windows 2000 and Windows XP drivers can be downloaded from the VEPD website at www.viaembedded.com. For embedded operating systems (Windows CE.NET and Windows XP Embedded), the related drivers can be found in the VIA Arena website at www.viaarena.com. -
Page 15: Contact
VB8001 Operating Guide Contact For more information on the VIA VB8001 Mini-ITX mainboard contact your sales representative or visit our website at www.viaembedded.com MERICA 940 Mission Court Fremont, CA 94539 Tel: (510) 683 3300 Fax: (510) 687 4654 Email: vpsd_sales@viatech.com TAIWAN 1F, No.
