- Page 1 USER MANUAL VB9001 High-integrated low-power platform ideal for network firewall and router applications 1.00-03142018-101000...
- Page 2 VIA Technologies, Inc. reserves the right the make changes to the products described in this manual at any time without prior notice.
-
Page 3: Safety Precautions
Battery Recycling and Disposal • Only use the appropriate battery specified for this product. • Do not re-use, recharge, or reheat an old battery. • Do not attempt to force open the battery. • Do not discard used batteries with regular trash. •... -
Page 4: Box Contents
VB9001 User Manual Box Contents • 1 x VB9001 board • 1 x SATA cable with SATA power • 1 x VGA cable Ordering Information Part Number Description VB9001-10E 3.5” SBC Board with 1.06GHz VIA Eden® X1 CPU, VGA, 4 USB 2.0, COM, DIO,... -
Page 5: Table Of Contents
VB9001 User Manual Table of Contents 1. Product Overview ....................... 1 Key Features ............................1 1.2 Product Specifications ......................... 2 Layout Diagram ............................ 4 Product Dimensions ..........................5 1.5 Height Distribution ..........................6 2. External I/O Pin Descriptions and Functionality ..............7 COM port .............................. 7 Gigabit Ethernet Port ..........................7 DC-in Jack ............................ - Page 6 VB9001 User Manual 6.6.5 Board Configuration ........................28 6.6.5.1 S5 Wake On LAN ........................ 28 6.7 Chipset Settings ..........................29 6.7.1 DRAM Configuration ........................30 6.7.1.1 DRAM Clock ........................30 6.7.1.2 VGA Share Memory (Frame Buffer) ................... 30 6.7.2 Watchdog Timer Control ......................31 6.7.2.1 Watchdog Timer Enable ....................31 6.7.2.2...
- Page 7 VB9001 User Manual List of Figures Figure 1: Layout diagram of the VB9001 (back panel I/O) .................. 4 Figure 2: Layout diagram of the VB9001 (right side) .................... 4 Figure 3: Layout diagram of the VB9001 onboard (top side) ................4 Figure 4: Layout diagram of the VB9001 onboard (bottom side) ................. 4 Figure 5: Mounting holes and dimensions of the VB9001 ................... 5 Figure 6: External I/O port dimensions of the VB9001 (back panel) ..............5 Figure 7: External I/O port dimensions of the VB9001 (right side) ..............5 Figure 8: Height distribution of the VB9001 (top side) ..................6 Figure 9: Height distribution of the VB9001 (bottom side) .................. 6 Figure 10: COM port diagram ..........................
- Page 8 VB9001 User Manual List of Tables Table 1: COM port pinouts ..........................7 Table 2: Gigabit Ethernet port pinouts ....................... 7 Table 3: Gigabit Ethernet port LED color definitions ..................8 Table 4: DC-in jack pinouts ..........................8 Table 5: DC-in jack specification pinouts ......................8 Table 6: USB 2.0 pin header pinouts ........................9 Table 7: Front panel pin header pinouts ......................
-
Page 9: Product Overview
VB9001 User Manual 1. Product Overview Based on a highly compact 3.5” SBC form factor, the VIA VB9001 combines the advanced performance of the fanless 1.06GHz VIA Eden® X1 processor with the enhanced multimedia capabilities of the VIA VX900 media system processor. The VIA VB9001 features of five Gigabit Ethernet ports, which makes it an ideal platform for network security, distributed control system (DCS), and monitoring applications. Measuring just 146mm x 102mm, the VIA VB9001 includes 1GB DDR3 SDRAM onboard and features a unique set of I/O and connectivity options ideal for high-speed M2M and IP camera applications, including two USB 2.0 ports, five Gigabit Ethernet ports, and one COM port, as well as onboard pin headers for VGA and DIO (4... -
Page 10: Product Specifications
VB9001 User Manual Product Specifications Processor • 1.06GHz VIA Eden® X1 (Fanless) Chipset • VIA VX900 Media System Processor BIOS • AMI Aptio UEFI BIOS, 8Mbit Flash memory System Memory • 1GB DDR3 SDRAM onboard Storage • 1 x SATA connector • 1 x CFast slot Graphic • Integrated VIA C-9 HD DX9 3D/2D graphics with MPEG-2, WMV9, VC1 and H.264 video decoding acceleration • 5 Realtek RTL8111G PCIe Gigabit Ethernet controllers Onboard I/O •... - Page 11 VB9001 User Manual VIA Smart ETK • BIOS flash tool, Hardware monitor, Watchdog timer, GPIO Operating Temperature • 0°C ~ 60°C Operating Humidity • 0% ~ 95% (non-condensing) Form Factor • 3.5" SBC (146mm x 102mm, 5.7" x 4") Compliance • CE • FCC Note: As the operating temperature provided in the specifications is a result of the test performed in VIA’s chamber, a number of variables can influence this result. Please note that the working temperature may vary depending on the actual situation and environment. It is highly recommended to execute a solid testing program and take all the variables into consideration when building the system. Please ensure that the system runs well under the operating temperature in terms of application.
-
Page 12: Layout Diagram
VB9001 User Manual Layout Diagram Gigabit Ethernet Figure 1: Layout diagram of the VB9001 (back panel I/O) DC-in Figure 2: Layout diagram of the VB9001 (right side) Fan connector 1.06GHz VIA Eden X1 CPU VIA VX900 chipset GPIO SATA power... -
Page 13: Product Dimensions
146mm Figure 5: Mounting holes and dimensions of the VB9001 126mm 106mm 87mm 68mm 49mm 22mm 1.6mm Figure 6: External I/O port dimensions of the VB9001 (back panel) 29mm Figure 7: External I/O port dimensions of the VB9001 (right side) -
Page 14: Height Distribution
VB9001 User Manual Height Distribution Height: 8mm Height: 7mm Height: 25mm Height: 8mm Height: 10mm Figure 8: Height distribution of the VB9001 (top side) Height: 9mm Figure 9: Height distribution of the VB9001 (bottom side) -
Page 15: 2. External I/O Pin Descriptions And Functionality
2. External I/O Pin Descriptions and Functionality The VB9001 has a wide selection of interfaces integrated into the system. It includes a selection of frequently used ports as part of the external I/O coastline. COM port The VB9001 is equipped with a COM port which supports RS-232. The pinouts of the COM port are shown below. Signal Figure 10: COM port diagram... -
Page 16: Dc-In Jack
VB9001 User Manual Each Gigabit Ethernet port has two individual LED indicators located on the front side to show its Active/Link status and Speed status. Link LED Active LED (Left LED on RJ-45 port) (Right LED on RJ-45 port) Link off LED is off LED is off Link LED Active LED Speed_10Mbit No flash Orange Flash Speed_100Mbit The Green LED is on Orange Flash Speed_1000Mbit The Red LED is on... -
Page 17: Onboard I/O
USB2 USB1 Figure 14: USB 2.0 pin header diagram Front Panel Pin Header The VB9001 comes with a front panel pin header which provides access to the system LED, HDD LED, power button and reset switch. The front panel pin header is labeled as “F_PANEL1". The pinouts of the front panel pin header are shown below. Signal Signal... -
Page 18: Spi Connector
VB9001 User Manual SPI Connector The VB9001 comes with a SPI flash connector which is labeled as "SPI1". The SPI (Serial Peripheral Interface) flash connector is used to connect the SPI BIOS programming fixture for updating the SPI flash ROM. The pinouts of the SPI connector are shown below. Signal MSPIDO MSPIDI MSPICLK MSPISSO SPIVCC Table 8: SPI connector pinouts SPI1 Figure 16: SPI connector diagram LPC Pin Header The VB9001 has one LPC pin header labeled as "LPC1" which is used for connecting LPC devices. The pinouts of the LPC pin header are shown below. -
Page 19: Gpio Pin Header
VB9001 User Manual GPIO Pin Header The VB9001 comes with a GPIO pin header labeled as “GPIO1”which supports up to 8 GPI and 8 GPO signals. The 8 input and 8 output signals can be programmed to read or control devices, with input or output defined. The pinouts of the GPIO pin header are shown below. Signal Pin Signal... -
Page 20: Sata Connector
Figure 20: SATA connector diagram SATA Power Connector The VB9001 comes with a SATA power connector which is used to power the SATA hard drive. The SATA power connector is labeled as “SATA_PWR1”. The pinouts of the SATA power connector are shown below. -
Page 21: Fan Connector
VB9001 User Manual Fan Connector The VB9001 comes with a fan connector labeled as “FAN1” which is used for connecting the system fan. The pinouts of the fan connector are shown below. Pin Signal FAN1 Table 14: Fan connector pinouts Figure 22: Fan connector diagram 3.10 CMOS Battery Connector The VB9001 is equipped with a CMOS battery connector used for connecting the external cable battery that provides power to the CMOS RAM. If disconnected all configurations in the CMOS RAM will reset to factory defaults. The CMOS battery connector is labeled as “BAT1”. The CMOS battery connector pinouts are shown below. Pin Signal BAT1 Table 15: CMOS battery connector pinouts... -
Page 22: 3.11 Cfast Slot
VB9001 User Manual 3.11 CFast Slot The VB9001 comes with a CFast slot labeled as "CFast1" which is compatible with Type I and Type II CFast cards. The pinouts of the CFast slot are shown below. Signal Signal STXP_1 PC2 STXN_1 PC3 SRXN_1 PC5 SRXP_1 PC6 PC10 NA PC11 NA PC12 NA PC13 CFAST_PWR PC14 CFAST_PWR PC15 GND CFast1 PC16 GND... -
Page 23: Onboard Jumpers
VB9001 User Manual 4. Onboard Jumpers Jumper Description A jumper consists of a pair of conductive pins used to close in or bypass an electronic circuit to set up or configure a particular feature using a jumper cap. The jumper cap is a small metal clip covered by plastic. It performs like a connecting bridge to short (connect) the pair of pins. The usual colors of the jumper cap are black/red/blue/white/yellow. Jumper Setting There are two settings of the jumper pin: “Short and Open”. The pins are “Short” when a jumper cap is placed on the pair of pins. The pins are “Open” if the jumper cap is removed. In addition, there are jumpers that have three or more pins, and some pins are arranged in series. In case of a jumper with three pins, place the jumper cap on pin 1 and pin 2 or pin 2 and 3 to Short it. -
Page 24: Clear Cmos Jumper
VB9001 User Manual Clear CMOS Jumper The VB9001 comes with a Clear CMOS jumper. The onboard CMOS RAM stores system configuration data and has an onboard battery power supply. To reset the CMOS settings, set the jumper on pins 2 and 3 while the system is off, then return the jumper to pins 1 and 2 afterwards. Setting the jumper while the system is on will damage the mainboard. The default settings are on pins 1 and 2. CMOS1 Figure 26: Clear CMOS jumper diagram Setting Pin 1 Pin 2 Pin 3 Normal Short Short Open Clear CMOS Open Short Short Table 17: Clear CMOS jumper settings Note: Except when clearing the RTC RAM, never remove the cap from the CLEAR_CMOS jumper default position. -
Page 25: 5. Hardware Installation
VB9001 User Manual 5. Hardware Installation Suggested minimum chassis dimensions The VB9001 can be fitted into any chassis that has mounting holes compatible with the standard SBC mounting hole locations. Additionally, the chassis must meet the minimum height requirements for specified areas of the mainboard. 5.1.1 Suggested minimum chassis dimensions The figure below shows the suggested minimum space requirements that a chassis should have in order to work well with the VB9001. 1.5mm Figure 27: Suggested minimum chassis dimensions Each side of the mainboard should have a buffer zone from the internal wall of the chassis. The side of the mainboard that accommodates the I/O coastline should have a buffer of 1.5mm; it's comprised of one COM port, and five Gigabit Ethernet ports. The side on the opposite end of the I/O coastline should have a buffer of at least 1mm. The right side of the I/O coastline should have a buffer of 1mm and it's only comprised of a DC-in jack. The left side of the I/O coastline should have a buffer of at least 5mm. -
Page 26: Suggested Minimum Chassis Height
VB9001 User Manual 5.1.2 Suggested minimum chassis height The figure below shows the suggested minimum height requirements for the internal space of the chassis. It is not necessary for the internal ceiling to be evenly flat. What is required is that the internal ceiling height must be strictly observed for each section that is highlighted. 20mm 30mm 32mm Figure 28: Suggested minimum chassis height (top side) 13mm Figure 29: Suggested minimum chassis height (bottom side) -
Page 27: Suggested Keepout Areas
VB9001 User Manual 5.1.3 Suggested keepout areas The figure below shows the areas of the mainboard that we recommend should be left unobstructed. The figures below are the top view and the bottom view. Keepout area Keepout area Keepout area Keepout area Figure 30: Suggested keepout top areas Keepout area Keepout area Figure 31: Suggested keepout bottom areas... -
Page 28: 6. Bios Setup Utility
VB9001 User Manual 6. BIOS Setup Utility Entering the BIOS Setup Utility Power on the computer and press Delete during the beginning of the boot sequence to enter the BIOS Setup Utility. If the entry point to the BIOS setup utility has passed, restart the system and try again. Control Keys Move up one row Down Move down one row Left Move to the left in the navigation bar... -
Page 29: Main Menu
VB9001 User Manual Main Menu The System Overview screen is the default screen that is shown when the BIOS Setup Utility is launched. This screen can be accessed by traversing the navigation bar to the “Main” label. Aptio Setup Utility Copyright (C) 2011 American Megatrends, Inc. Main Main Advanced Chipset Boot Save & Exit BIOS Information Choose the system default BIOS Vendor American Megatrends language. Core Vendor 4.6.4.0 Compliancy UEFI 2.0 Project Version H5400 1.03 x64... -
Page 30: Advanced Setting
VB9001 User Manual Advanced Setting The Advanced Settings screen shows a list of categories that can provide access to a sub-screen. The Sub- screen links can be identified by the preceding right-facing arrowhead. Aptio Setup Utility Copyright (C) 2011 American Megatrends, Inc. Main Advanced Advanced Chipset Boot Save & Exit S5 RTC Wake Settings Enable system to wake from S5 CPU Configuration using RTC alarm. IDE Configuration... -
Page 31: S5 Rtc Wake Settings
VB9001 User Manual 6.6.1 S5 RTC Wake Settings This section enables the S5 RTC Wake system to wake from S5 using RTC alarm. Aptio Setup Utility Copyright (C) 2011 American Megatrends, Inc. Advanced Wake system with Fixed Time [Disabled] Enables or disables System wake on alarm event. When enabled, Wake system with Dynamic Time [Disabled] System will wake on the... -
Page 32: 6.6.1.1.1 Wake Up Hour
VB9001 User Manual 6.6.1.1.1 Wake up hour Select 0-23. For example: Enter 3 for 3am and 15 for 3pm 6.6.1.1.2 Wake up minute Select 0-59 for minutes. 6.6.1.1.3 Wake up second Select 0-59 for seconds. 6.6.1.2 Wake system with Dynamic Time This feature has 2 options: Enable or Disable system wake on the alarm event. When enabled, the system will... -
Page 33: Cpu Configuration
VB9001 User Manual 6.6.2 CPU Configuration The CPU Configuration screen shows detailed information about the built-in processor. Aptio Setup Utility Copyright (C) 2011 American Megatrends, Inc. Advanced CPU Configuration VIA Eden C1050@1.06GHz Speed (FSB 266MHz * 4): 1064MHz Core L1 Cache RAM 64 k L2 Cache RAM 2048 k Microcode Revision... -
Page 34: Ide Configuration
VB9001 User Manual 6.6.3 IDE Configuration The IDE Configuration screen allows the user to view and configure the settings of the IDE Configuration. Aptio Setup Utility Copyright (C) 2011 American Megatrends, Inc. Advanced IDE Configuration SATA Port0 Not Present SATA Port1 Not Present : Select Screen : Select Item Enter: Select +/-: Change Opt. F1: General Help... -
Page 35: Clock Generator Configuration
VB9001 User Manual 6.6.4 Clock Generator Configuration The Clock Generator Configuration screen enables access to the Spread Spectrum Setting feature. Aptio Setup Utility Copyright (C) 2011 American Megatrends, Inc. Advanced CPU Spread Spectrum CPU Spread Spectrum [+-0.25%] PCIe Spread Spectrum [+-0.25%] : Select Screen : Select Item Enter: Select +/-: Change Opt. F1: General Help... -
Page 36: Board Configuration
VB9001 User Manual 6.6.5 Board Configuration The Board Configuration screen below shows the main setting of the S5 Wake On LAN functions. Aptio Setup Utility Copyright (C) 2011 American Megatrends, Inc. Advanced S5 Wake On LAN [Disabled] S5 Wake On LAN : Select Screen : Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save &... -
Page 37: Chipset Settings
VB9001 User Manual Chipset Settings The Chipset Settings screen shows a list of categories that can provide access to a sub-screen. The sub-screen links can be identified by the preceding right-facing arrowhead. Aptio Setup Utility Copyright (C) 2011 American Megatrends, Inc. Main Advanced Chipset Chipset Boot Save & Exit DRAM Configuration DRAM Configuration Watchdog Timer Control : Select Screen : Select Item Enter: Select +/-: Change Opt. -
Page 38: Dram Configuration
VB9001 User Manual 6.7.1 DRAM Configuration The DRAM Configuration screen has two features for controlling the system DRAM. All other DRAM features are automated and cannot be accessed. Aptio Setup Utility Copyright (C) 2011 American Megatrends, Inc. Chipset Memory Information Select DRAM Frequency. Current FSB Frequency 1066 MHz Current DRAM Frequency 1066 MHz 1024 MB (DDR3) Total Memory... -
Page 39: Watchdog Timer Control
VB9001 User Manual 6.7.2 Watchdog Timer Control The Watchdog timer control screen has features for controlling the Watchdog timer. The sub-screen links can be identified by the preceding right-facing arrowhead. Aptio Setup Utility Copyright (C) 2011 American Megatrends, Inc. Chipset WATCHDOG Timer Enable [Enabled] Enable/Disable WATCHDOG Timer WATCHDOG Timer RUN/STOP [STOP] [Power Off] WATCHDOG Timer ACTION [1023 SEC] WATCHDOG Timer COUNT... -
Page 40: Boot Settings
VB9001 User Manual Boot Settings The Boot Settings screen has a single link that goes to the Boot Configuration and Boot Option Priorities screens. Aptio Setup Utility Copyright (C) 2011 American Megatrends, Inc. Main Advanced Chipset Boot Boot Save & Exit Boot Configuration Number of seconds to wait for Setup Prompt Timeout setup activation key. Bootup NumLock State... -
Page 41: 7. Software And Technical Support
VB9001 User Manual 7. Software and Technical Support Microsoft Windows & QNX Support The VB9001 features a complete software evaluation image featuring Microsoft Windows 7, Windows CE 5.0 and QNX operating system. VIA Smart ETK The VB9001 features a complete software evaluation image featuring VIA Smart ETK. Technical Supports and Assistance •For utilities downloads, latest documentation and new information about the VB9001, please visit our website at https://www.viatech.com/en/boards/3-5-inch-sbc/vb9001/ •For technical support and additional assistance, always contact your local sales representative or board distributor, or go to https://www.viatech.com/en/support/driver-support-faq/technical-support/ for technical support. •For OEM clients and system integrators developing a product for long term production, other code and resources may also be made available. Please visit our website at https://www.viatech.com/en/about/... -
Page 42: Appendix.a. Installing Wireless Accessories
A.1. Installing EMIO-5531 USB Wi-Fi & Bluetooth module Step 1 Mount the EMIO-5531 to the prepared standoff in the chassis. Align the two mounting holes on the EMIO- 5531 module with the mounting holes on the standoffs, then secure the EMIO-5531 module in place with two screws. Figure 45: Installing EMIO-5531 to the chassis Step 2 Connect one end of the USB Wi-Fi cable to pin 1, 3, 5, and 7 of the onboard USB 2.0 pin header (USB1 or USB2) on the VB9001 board, and then connect the other end of the cable to the EMIO-5531 module. Figure 46: Connecting USB cable Wi-Fi cable... -
Page 43: Figure 47: Installing Wi-Fi Antenna Cable And Antenna
VB9001 User Manual Step 3 Insert the Wi-Fi antenna cable into the antenna hole from the inside of the panel I/O plate. Insert the toothed washer, fasten it with the nut, and install the external antenna. P a n e l I... - Page 44 Taiwan Headquarters Japan China 1F, 531 Zhong-zheng Road, 940 Mission Court 3-15-7 Ebisu MT Bldg. 6F, Tsinghua Science Park Bldg. 7 Xindian Dist., New Taipei City 231 Fremont, CA 94539, Higashi, Shibuya-ku No. 1 Zongguancun East Road, Taiwan Tokyo 150-0011 Haidian Dist., Beijing, 100084 Japan China...
