Operating Guide
VB8002 Mainboard
June 26, 2009
Version 1.01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VB8002 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VIA Technologies VB8002

Summary of Contents for VIA Technologies VB8002

  • Page 1 Operating Guide VB8002 Mainboard June 26, 2009 Version 1.01...

  • Page 2: Table Of Contents

    C. Running Network Applications - Copying Files (VT6122) ..........7 D. Idle...........................7 E. Running C.C. Winstone 2004 ..................8 F. S3 Mode ........................8 Power Specifications ......................9 VIA VB8002 Microsoft and Linux Driver Support ..............10 Microsoft Driver Support....................10 Linux Driver Support......................10 Contact ..........................11 June 26, 2009 - i - Version 1.01...

  • Page 3: Via Vb8002 Overview

    USB ports using the available onboard pin headers), and a 10/100 Fast Ethernet port for extended broadband connectivity. The VIA VB8002 also has one PCI slot for expandability options. The VIA VB8002 is compatible with a full range of Mini-ITX chassis as well as FlexATX and MicroATX enclosures and power supplies.

  • Page 4: Via Vb8002 Layout

    VB8002 Operating Guide VIA VB8002 Layout June 26, 2009 - 2 - Version 1.01...

  • Page 5: Via Vb8002 Specifications

    VB8002 Operating Guide VIA VB8002 Specifications Model Name VB8002 VIA Nano 1.6GHz NanoBGA2 processor Processor Chipset - VIA CX700M2 advanced all-in-one system processor System Memory - 1 DDR2 533 DIMM socket - Up to 1GB memory size - Integrated VIA UniChromeTM Pro II 3D/2D AGP graphics with MPEG-2/4 and...

  • Page 6: Via Vb8002 Processor Sku

    VB8002 Operating Guide VIA VB8002 Processor SKU The VIA VB8002 is available in the following speed grade: • 1.6 GHz VIA Nano NanoBGA2 Processor June 26, 2009 - 4 - Version 1.01...

  • Page 7: Via Vb8002 I/O Back Panel Layout

    SPDIF port, one set of composite audio/video outputs and one set of component video outputs. In addition to the ports available on the back panel, the VB8002 also supports a host of connectivity options through PS2 mouse/keyboard pin header, LPC pin header, USB 2.0 pin headers, video pin header (CCIR656/601 and SMBus), TV-out pin header, LVDS connector, SATA connectors, and front audio jacks.

  • Page 8: Via Vb8002 Dimensions & Mounting Holes

    VB8002 Operating Guide VIA VB8002 Dimensions & Mounting Holes June 26, 2009 - 6 - Version 1.01...

  • Page 9: Power Consumption

    VB8002 Operating Guide Power Consumption Power consumption tests were performed four different configurations. The following tables are a comprehensive breakdown of the mainboard’s voltage, amp and wattage values while running common system applications. VB8002     1.6 GH WITH A.

  • Page 10: Running C.c. Winstone 2004

    VB8002 Operating Guide E. Running C.C. Winstone 2004 Measured Voltage Measure Amp Watts Main Board +3.3V 3.273 1.568 5.132 Main Board +5V 4.865 3.408 16.580 Main Board 5VSB 4.987 0.205 1.022 Main Board +12V 12.211 0.168 2.051 Total Power Consumption 24.785...

  • Page 11: Power Specifications

    VB8002 Operating Guide Power Specifications The VIA VB8002 mainboard utilizes an industry standard 20-pin ATX power connector for connecting to the power supply. Due to its ultra low power requirements, a 90 – 120 Watt ATX power supply is ample for even the heaviest of multimedia system applications.

  • Page 12: Via Vb8002 Microsoft And Linux Driver Support

    ICROSOFT RIVER UPPORT The VIA VB8002 mainboard is compatible with Microsoft operating systems. The latest Windows Windows 2000 and Windows XP drivers can be downloaded from the VEPD website at www.viaembedded.com. For embedded operating systems (Windows XP Embedded), the related drivers can be found in the VIA Arena website at www.viaarena.com.

  • Page 13: Contact

    VB8002 Operating Guide Contact For more information on the VIA VB8002 mainboard contact your sales representative or visit our website at www.viaembedded.com. MERICA 940 Mission Court Fremont, CA 94539 Tel: (510) 683 3300 Fax: (510) 687 4654 Email: vpsd_sales@viatech.com UROPE...
