PCI I/O Card Replacement
1
6
7
ccrr005
No.
1
I/O Card Cage
2
Outside I/O Card anchor screw
3
Short I/O Card #1 (may be Secure Web Console)
4
I/O Card Cage anchor quarter-turn fasteners
5
I/O Backplane disconnect lever
254
2
8
Name
3
5
9
4
No.
6
I/O Card anchor screws
7
I/O Cards #2 through #4
8
I/O Backplane anchor screw
9
I/O Backplane
Name
Chapter
