Add Peripheral Component Interconnect (PCI) Cards
Load Product
Order Number
18 A3739B
19 A5150A
20 A5149A
21 A5486A
22 A5159A
23 J3526A
24 A5858A
25 A6150
(F) = Full length I/O card -- (H) = Half length I/O card. NA = Not Applicable
Notes:
1. Use in slot No. 2 ONLY. Cannot be used in slots 1, 3, or 4.
2. Provides web-based console capability on any PC with a browser. If needed, this card must be ordered
with the A500 server. Cannot be ordered standalone. This card is not required if a system console
terminal is used. Cannot have both A5858A and System Console (C1099A) on the same order.
3. Use A6150-6002 Graphics card in slot 1 only.
4. e3000 systems only.
130
PCI Card Description
FDDI Dual Attach Station LAN
Adapter (H)
Dual Port Ultra2 SCSI (F)
Single port Ultra-2 SCSI
Interface card (F)
Public Key Cryptography (PKC)
PCI (F)
Dual Port FWD SCSI-2 (F)
Quad Port Serial (X25/FR) (F)
Secure Web Console PCI Card
(H) (Optional)
PCI 2D Graphics and 2 part
USB adapters (H)
Part # Max.
A3739-60002 4
A5150-60001 3
A5149-60001 3
A5486-60001 3
A5159-60001 3
5063-1322 3
A5858-70001 1
A6150-60001/ 1
A6150-60002
Future
Boot Notes
Rel.
No
Yes x 4
Yes 4
No x
Yes x 4
No x
No 2
No 3
Chapter
