ADJUST ANTENNA ANGLE
Safety distance should be calculated according to the conditions of installation site.
Followings show the calculation examples:
 Calculation Example 1 (Front Side of Antenna)
 Calculation Example 2 (Rear Side of Antenna)
The safety distance that is obtained by the conditions above and is below the value
defined by COUNCIL RECOMMENDATION (1999/519/EC) of 1 mW/cm² is:
iPASOLINK EX Advanced: I
 Output Power = +18 dBm
 Antenna Diameter = 0.6 m
 Antenna Gain = 52 dBi
 Distance = 9.0 m

Output Power Density : S = 0.982 mW/cm
Limit: Output Power Density S = 10 (W/m
COUNCIL RECOMMENDATION
*:
limitation of exposure of the general public to electromagnetic fields (0 Hz to 300 GHz)

Output Power = +18 dBm

Antenna Diameter = 0.6 m

Antenna Gain = –16 dBi

Distance = 0.004 m = 4.0 mm

Output Power Density : S = 0.788 mW/cm
Limit: Output Power Density S = 10 (W/m
COUNCIL RECOMMENDATION
*:
limitation of exposure of the general public to electromagnetic fields (0 Hz to 300 GHz)
Front Side of Antenna (X)  9.0 m

Rear Side of Antenna (Y)  0.004 m = 4.0 mm

NSTALLATION
2
 1 mW/cm
2 2
) = 1 (mW/cm )
*
(1999/519/EC) of 12 July 1999 on the
2
 1 mW/cm
2 2
) = 1 (mW/cm )
*
(1999/519/EC) of 12 July 1999 on the
8-13
