CONNECT CABLES
5.6.2 Secure Cables (for 1+0 System)
Secure the cables as shown below:
1. Tie cables.
2. Then secure tied cables onto the pole.
iPASOLINK EX Advanced: I
Figure 5-24 Secure Cables (1+0 System) — V-Polarization
secure them onto pole
NSTALLATION
5-15
tie cables
GGS-000546-13E
