CONNECT CABLES
4. Turn the waterproofing cap clockwise to lock the cap.
BARREL
BUSHING
WITH RIB
5. Tighten the Gland Nut at the barrel end level, and secure them using the torque
wrench.
This step ends the procedure.
 Refer to
iPASOLINK EX Advanced: I
Figure 5-21 Set Bushing into Barrel
RIB
(GLAND NUT)
5.6 Routing Cables
NSTALLATION
Check that the bushing is fully inserted
within the barrel end.
Figure 5-22 Secure Gland Nut
to end the Cable Connecting procedure.
