MOUNT iPASOLINK EX/A
4.2.1.2
H mark is found on the bottom left of the grip. To mount the equipment on left to the
pole, place the equipment showing its H mark on top. To mount the equipment on
right to the pole, place the equipment showing its H mark on bottom:
Figure 4-2 H-Polarization and Position to Install
(to mount the equipment on left to the pole)
iPASOLINK EX Advanced:I
Polarization: Horizontal
H
NSTALLATION
H
(to mount the equipment on right to the pole)
