ADJUST ANTENNA ANGLE
Figure 8-2 Step 1 Detailed Equipment / Radio Setting Window
.
2. Repeat steps above at the opposite site.
3. Prepare to measure RX Level:
CAUTION:
NOTES:
iPASOLINK EX Advanced: I
(4) Select MTPC if a different value is selected at TX Power Control
parameter.
Surface of iPASOLINK EX/A may be hot during the operation.
Ensure not to touch the equipment by mistake.
(1) Remove a protective cap from RSL terminal on iPASOLINK EX/A, and
connect a digital multimeter to it. Refer to Figure 8-3.
(2) Monitor the reception levels at both the local and opposite site, and adjust
the reception levels to be maximum by turning antenna up and down and/
or left to right. Refer to Section 8.3 Adjust Antenna Angle.
1. RSL monitor conforms to IEC61169-24.
2. Put the waterproofing cap back to the RSL terminal to protect it after
checking.
