5-6
(2) Place and set the housing:
(3) Push the housing till the plug is fit at the end of the shell.
BUSHING WITH RIB
GGS-000546-13E
Figure 5-6 Connecting a Plug
Figure 5-7 Place Housing
HOUSING
Figure 5-8 Place Plug Housing
BARREL
HOUSING
GLAND NUT
iPASOLINK EX Advanced: I
CONNECT CABLES
no gap
gasket is
seen
NSTALLATION
