Securing the adjacent units to the corner
post
Place the adjacent base unit next to the
corner post in line with the markings on the
wall. Both of the runs must be straight and
the units must be level.
Screw into the side of the unit using 2x30mm
screws, where possible, these should be
positioned in front of the hinge plates.
Screw 9mm in from the edge of the unit, in
the centre of the hinge plates (if possible).
This will ensure the unit is attached to Packer
Y1.
Place a cover cap on the heads to conceal the
visible screw heads.
Securing to adjacent units
Clamp together the two units, checking the
front edges are level and flush.
Using the screws provided, 1x30mm screw
should be fixed into each corner of the
carcase side.
The screws can be concealed by placing
them behind the shelf or behind the hinge
plates. The cover caps can be used to hide
any visible screw heads that remain.
