Wren Kitchens INFINITY PLUS Base Unit Fittings Manual page 6

Cutting for the services method 1
Measuring the services
Measure the distance between the centre of
the services and the wall markings.
Transfer the markings onto the inside of the
unit back panel.
Ensure to double check the measurements by placing the unit in line with the wall markings and
check the marking is in the same place as the services.
Drilling the back of the unit
Drill a hole using the correct holesaw for the
size of the pipe at the marked locations.
Cutting for the services method 2
Removing the back staples
Using a flat-headed screwdriver, carefully
remove the staples located at the bottom of
the unit.
Any minor damage to the back panel will be
concealed once the unit is positioned against
the wall.
Page 6
