2. Specifications

2.1.

Core System

CPU: Dual or quad-core Intel
•
Pentium N3710 1.6/2.56 (Burst) GHz 6W (4W SDP) (4C/1600)
®
•
Celeron N3160 1.6/2.24 (Burst) GHz 6W (4W SDP) (4C/1600)
®
•
Celeron N3060 1.6/2.48 (Burst) GHz 6W (4W SDP) (2C/1600)
®
•
Celeron N3010 1.04/2.24 (Burst) GHz 4W (3W SDP) (2C/1600)
®
•
Atom x5-E8000 1.04/2.00 (Burst) GHz, 5W (4W SDP) (4C/1600)
TM
Supports: Quad Out-of-Order Execution (OOE) processor cores, Intel® VT-x, support 36-bit physical address, 48-bit linear address size
Note: Availability of features dependent on processor SKU, Intel
Cache: Cores are grouped into dual-core modules
One die, 32 KB, 8-way L1 instruction cache and 24 KB, 6-way L1 data cache per core
One die, 1 MB, 16-way L2 cache, shared per two cores (module)
Memory: Dual channel non-ECC 1600/1333 MHz DDR3L memory up to 8GB in dual stacked SODIMM sockets
Embedded BIOS: AMI EFI in 8MB SPI BIOS
2.2.

Rear I/O Connectors

Display: 2x DisportPort, 1x HDMI
LAN: Dual GbE RJ-45
USB: 4x USB 3.0
Aduio: Line-Out, Mic-In
Power: Screw Jack for 12V DC-in
2.3.

Internal Headers and Connectors

PCIe x1 slot
2x Mini PCIe slots: one PCIe + USB; one mSATA + USB
USB: 2x USB 2.0 via onboard header, 2x USB 2.0 via front panel connector
SATA: 2x SATA 6Gb/s (SATA0, SATA1)
SATA Power Connector
Serial: 2x RS-232 headers, 2x RS-232/422/485 headers with 5V power (12V by BOM option)
LVDS (optional): dual-channel 18/24-bit, switched from DisplayPort (build option)
eDP (optional): switched from DisplayPort ((build option, not available concurrently with LVDS)
SIM Card slot (build option)
microSD Card slot (build option)
Front Panel Header
Audio Header
Feature Connector Header
PS/2 KB/MS Connector
TPM Header
SPI Header
ATX Power Connector (4-pin)
Page 8
Pentium , Celeron , Atom™ Processor SoC
® ® ®
Hyper-Threading Technology is not supported
®
