2.4.

Form Factor

Mini-ITX: 170mm x 170mm
2.5.

SEMA Board Controller

ADLINK Smart Embedded Management Agent (SEMA)
•
Voltage/Current monitoring
•
Power sequence debug support
•
AT/ATX mode control
•
Logistics and Forensic information
•
Flat Panel Control
•
General Purpose I2C
•
Failsafe BIOS (dual BIOS )
•
Watchdog Timer and Fan Control
2.6.

Debug Header

40-pin Multipurpose Flat Cable Connector:, used in combination with DB-40 debug module providing BIOS POST code LED, BMC
access, SPI BIOS flashing, Power Testpoints, Debug LEDs
2.7.

Video

GPU Feature Support: Gen 8-LP Intel
•
Hardware acceleration:
3-D: DirectX 11.1, OpenGL, 4.2, OpenGL ES 3.0, OpenCL 1.2
2-D: HEVC, H.264, MPEG2, VC-1 WMV9
•
Hardware video decode: H.265/HEVC @ level 5, H.264 @ level 5.1, MPEG2, MVC, VC-1, VP8, WMV9, JPEG, VP8
•
Hardware video encode: H.264 @ level 5.1, MVC, JPEG
Note: Availability of features dependent on processor SKU and may vary between operating systems.
Display Interface Support
•
DisplayPort: Supports DP1.1a, maximum resolution: 3840x2160 @ 30Hz, 2560x1600 @ 60Hz
•
HDMI: Supports HDMI 1.4b, maximum resolution: 3840x2160 @ 30Hz, 2560x1600 @ 60Hz
•
LVDS (optional): Supports single/dual channel 18/24-bit, up to 1920x1200 @ 60 Hz
•
eDP (optional): Supports eDP 1.4, maximum resolution: 2560x1440 @ 60Hz
2.8.

Audio

Audio Codec: ALC886
2.9.

LAN

Intel MAC/PHY: Intel® i211AT (MAC/PHY) Ethernet controller
Interface: 10/100/1000 GbE connection

2.10. Power Specification

Power Modes:
Standard Voltage Input:
Power Management:
Power States:
AmITX-BW-I
graphics core with 16 execution units supporting maximum of three simultaneous displays
®
AT and ATX mode (AT mode start controlled by BMC)
12VDC ±5%
ACPI 4.0 compliant
Supports C0, C1, C1E, C6C, C6, C7, S0, S1, S3, S4, S5 (Wake-on-USB S3/S4, WoL S3/S4/S5)
