1. Introduction

The AmITX-BW-I is a low-profile Thin Mini-ITX embedded board supporting an Intel
Atom™ processor x5-E8000 system-on-chip (SoC). The AmITX-BW-I is specifically designed for customers who need significant graphics
performance with low power consumption in a long product life solution.
The Intel Pentium /Celeron processor N3000 family and Intel Atom™ processor x5-E8000 SoC (formerly "Braswell") are built on 14nm
® ® ®
technology and support non-ECC type DDR3L dual-channel memory at 1600/1333 MHz to provide excellent overall performance. Integrated
Intel® Gen 8 Graphics includes features such as OpenGL 4.2, DirectX 12, OpenCL 1.2 and support for H.265/HEVC @ level 5, H.264 @
level 5.1, MPEG2, MVC, VC-1, VP8, WMV9, JPEG, VP8 hardware video decode and H.264 @ level 5.1, MVC, JPEG hardware video
encode.
The AmITX-BW-I supports dual stacked SODIMM sockets for up to 8 GB non-ECC type DDR3L memory, and graphics outputs include
DisplayPort, HDMI, and optional eDP and optional dual-channel 18/24-bit LVDS. I/O features include HD Audio, dual Gigabit Ethernet port,
4x USB 3.0 ports and 4x USB 2.0 ports, 6x COM ports, PCIe x1 slot, Mini PCIe slot, mSATA slot, and 2x SATA 6 Gb/s ports. A feature
connector provides 10 GPIO, SMBus, and I
with SPI AMI EFI BIOS, supporting embedded features such as hardware monitor and watchdog timer.
Model
AmITX-BW-I-N3710
AmITX-BW-I-N3160
AmITX-BW-I-N3060
AmITX-BW-I-N3010
AmITX-BW-I-E8000
Latest revision of the datasheet, user's manual, BIOS, drivers, and board support packages, can be downloaded from the product webpage:
http://www.adlinktech.com/PD/web/PD_detail.php?utm_source=&cKind=&pid=1572
1.1.

Packing List

•
AmITX-BW-I Thin Mini-ITX motherboard
•
SATA dual power cable (P/N: 30-20875-0000)
•
SATA cable (P/N: 30-10057-0600)
•
Standard rear I/O shield (P/N: 34-25317-0000)
1.2.

Optional Accessories

•
COM port cable, 1 port (P/N: 30-20876-0000)
•
PS/2 KB/MS cable (P/N: 30-20873-0000)
•
USB 2.0 cable, 2 ports (P/N: 30-20874-1000)
•
Low profile rear I/O shield (P/N: 34-25317-1000)
AmITX-BW-I
C, and optional SIM card slot and microSD card slot are available. The AmITX-BW-I is equipped
2
Intel Braswell SoC
Pentium ® N3710 (4 cores)
Celeron ® N3160 (4 cores)
Celeron N3060 (2 cores)
®
Celeron N3010 (2 cores)
®
Atom™ x5-E8000 (4 cores)
Pentium /Celeron
® ®
Core Speed (HFM/Burst) Thermal Design
Power (TDP)
1.6/2.56 GHz
1.6/2.24 GHz
1.6/2.48 GHz
1.04/2.24 GHz
1.04/2.00 GHz
processor N3000 family and Intel
®
Scenario Design
Power (SDP)
6W 4W
6W 4W
6W 4W
4W 3W
5W 4W
