3. Mechanical Layout
3.1.
Connector Locations
12V DC-in HDMI
CPU Fan
Feature Connector
Front Panel
Connector
Audio Connector
PCIe x1
USB Header
2x SATA2
mSATA Slot
2 Stacked SODIMM
Mini PCIe
Page 12
Rear I/O
DP DP
USB 3.0
Top Side Connectors
Line-out
Mic-in
12V DC-in
ATX Power
SPI Header/Socket
eDP
LVDS
6x RS-232
TPM
PS/2 KB/MS
System Fan
1
AmITX-BW-I
