Regency Alterra Pro i3000A Owners & Installation Manual page 2

|
2
The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment. Should you have any questions about your
product that are not covered in this manual, please contact the REGENCY DEALER in your area.
"This wood heater has a manufacturer set minimum low burn rate that must not be altered. It is against federal regulations to alter this
setting or otherwise operate this wood heater in a manner inconsistent with operating instructions in this manual." Failure to follow
the manual details can lead to smoke and CO emissions spilling into the home. It is recommended to have monitors in areas that are
expected to generate CO such as heater fueling areas.
"U.S. ENVIRONMENTAL PROTECTION AGENCY Certified to comply with 2020 particulate emission standards using crib wood."
Tested & listed to Method 28R, E2780 - 10, E2515 - 11. Model Regency i3000A/i3000R 0.95 g/hr.
"This manual describes the installation and operation of the Regency i3000A/i3000R wood heater. This heater meets the 2020 U.S. Environmental Protection
Agency's cord wood emission limits for wood heaters. Under specific test conditions, this heater has been shown to deliver heat at rates ranging from 13,794
Btu/hr to 33,155 Btu/hr." Efficiency is determined using the B415 method, resulting in lower and higher heat values. This heater generates the best efficiency
when operated using well-seasoned wood and installed in the main living areas where the majority of the chimney is within the building envelope. "
It is against federal regulation to operate this wood heater in a manner inconsistent with the operating instructions in this manual, or if elements are
deactivated or removed."
"This heater is designed to burn natural wood only. Higher efficiencies and lower emissions generally result when burning air-dried, seasoned hardwoods,
as compared to softwoods or to green or freshly cut hardwoods."
Burn untreated wood only. Other materials such as wood preservatives, metal
foils, coal, plastic,garbage, sulphur, or oil may damage the heater.
DO NOT BURN:
• Treated wood • Lawn clippings or yard waste
• Coal • Materials containing rubber including tires
• Garbage • Materials containing plastic
• Waste petroleum products , paints or paint thinners or asphalt
• Cardboard
products
• Materials containing asbestos
• Solvents
• Colored Paper • Construction or demolition debris
• Bio Bricks
• Trash • Railroad ties
Burning these materials may result in release of toxic fumes or render the heater ineffective and cause smoke.
The authority having jurisdiction (such as Municipal Building Department, Fire Department, Fire Prevention Bureau, etc.) should be
consulted before installation to determine the need to obtain a permit.
ULC628-2022 - Canada
This fireplace insert must be installed with a continuous chimney liner liner of 5.5 or 6 inch diameter extending from the fireplace insert to the top of the
chimney. The chimney liner must conform to the class 3 requirements of CAN/ULS-S635 Standard for lining systems for existing Masonry or factory built
chimneys and vents or to the requirements of CAN/ULC-S640, Standard for lining systems for new masonry chimneys.
UL1482-2022 - U.S.A
A chimney complying with the requirement for type HT chimneys in the standard for chimneys,factory built residential and building heating appliance UL103
or a code approved masonry chimney liner with a flue liner.
This fireplace insert must be installed with a continuous chimney liner liner of 5.5 or 6 inch diameter extending from the fireplace insert to the top of the
chimney. When this room heater is not properly installed, a house fire may result. To reduce the risk of fire follow the installation instructions. Contact local
building or fire official as about restrictions and installation requirements in your area.
i3000A/i3000R is tested and certified to CAN/ULC 628:2022 and UL 1482-2022.
SAVE THESE INSTRUCTIONS
2
|
Regency i3000A/i3000R
Thank you for purchasing a
REGENCY FIREPLACE PRODUCT.
To avoid burns or wood splinters, when opening/closing the fuel door or adding
wood to the fire, You should always wear appropriate protective gloves to
protect your hands from the heat being emitted from this fireplace.
• Manure or animal remains
• Saltwater driftwood or other previously salt
water saturated materials
• Unseasoned wood
• Paper products, cardboard, plywood, or
particle board. The prohibition against
burning these materials does not prohibit
the use of fire starters made from paper,
cardboard, saw dust, wax and similar sub-
stances for the purpose of starting a fire in
a wood heater.
