Alterra Pro™
i3000A/i3000R
Wood Fireplace
Insert
Owners & Installation Manual
www.regency-fire.com
MODEL:
i3000A/i3000R
Tested & listed by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
0219WN032S
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
07.24.24
920-346
